AUDIOAudio Bandwidth | 200Hz–7.5kHz
No. of Full-Duplex Audio Paths | Up to 5 with individual level control (2 dedicated rotaries, 3 within menu)
Mode of Operation | Full duplex on all routes
Level/Talk Controls | 4 pushbuttons, reply button, and 2 rotary controls
Enter/Answer-Back Button | 1
RADIOFrequency Spectrum | 2.400–2.483MHz for EU and US cellular auto roaming technology
Modulation | GFSK, TDMA frame 10ms full and long slot
Output Power | (EU) 18–22dBm, (US) 18–20dBm
Range | Typical indoor range 300ft (90m), outdoor range 800ft (240m)
Battery | Li-Ion or 3 AA alkaline cells
Battery Charging | Drop-in charger (AC60) or local USB
Battery Life | 18+ hours with Li-Ion; 9 hours with 3 AA alkaline cells
CONNECTORS & AUDIO INTERFACESHeadset Connector | 4-pin male, Clear-Com standard
Optional Connectors | 5-pin female and 7-pin male with PTT
Headset Voltage | Maximum of approximately +8dBu as set by firmware
Microphone Type | Electret and Dynamic, selectable in beltpack menu
Microphone Voltage | Electret Mic: -45dBu (additional 2.5V DC bias voltage positive on Pin 2 and negative on Pin 1 via a 1k resistor)
Headset Limiter | Selectable from beltpack menu
ENVIRONMENTAL & PHYSICALEnvironmental Rating | IP53 water and dust resistance
Operating Temperature | 32°–125°F (0°–50°C)
Storage Temperature | 32°–150°F (0°–70°C)
Humidity | 20%–90%, non-condensing
Dimensions | 3.75 x 5 x 1.5 in (HxWxD) / 97 x 130 x 45 mm
Weight | 9.0 oz (0.25kg), including batteries
