The L-Acoustics X8 is a 2-way passive coaxial loudspeaker that delivers high-fidelity sound in a compact form factor. It features an 8-inch low-frequency driver and a 1.5-inch diaphragm compression driver arranged coaxially, ensuring a 100° axisymmetric directivity pattern for consistent coverage. Equipped with L-Vents laminar venting technology, the X8 minimizes turbulence and port noise, enhancing low-frequency efficiency. Operating across a frequency range of 60 Hz to 20 kHz, it achieves a maximum SPL of 129 dB. Weighing 12 kg (26.5 lbs), the X8 is constructed from premium-grade Baltic beech and birch plywood, featuring a coated steel grill with acoustically neutral 3D fabric. Its versatile design allows for various mounting options, including pole, wall, ceiling, or flown configurations, making it ideal for live monitoring and short-throw sound reinforcement applications.
**System Data:**
- Frequency Response (-10 dB): 60 Hz – 20 kHz
- Maximum SPL (1 m, free field): 129 dB
- Nominal Directivity (-6 dB): 100° axisymmetric
- Monitoring Angle: 35°
**Transducers:**
- Low Frequency (LF): 1 × 8" cone driver
- High Frequency (HF): 1 × 1.5" diaphragm compression driver, neodymium
- LF Acoustical Load: Bass-reflex with L-Vents
- HF Acoustical Load: Conical waveguide
**Impedance:**
- Nominal Impedance: 8 Ω
**Connectors:**
- Input: 1 × 4-point SpeakON
- Link: 1 × 4-point SpeakON
**Rigging and Handling:**
- Handles: 1 integrated handle
- Threaded Inserts: 4 × M10 for rigging; 1 × M8 (DIN580) for safety
- Mounting: 35 mm pole socket
- Monitoring Angle Adjustment: 35° monitor angle setting
**Physical Specifications:**
- Cabinet Material: Premium-grade Baltic beech and birch plywood
- Front Protection: Coated steel grill with acoustically transparent 3D fabric
- Finish Options: Dark grey brown (Pantone 426 C), Pure white (RAL 9010); custom RAL codes available upon special order
- Weight (Net): 12 kg (26.5 lbs)
- Ingress Protection Rating: IP43
